NR-C001
Raising
| Quantity: | |
|---|---|
Model:NR-C001 | Material | Brass CW617N,HPB59-1,DZR CW602N,lead free brass C46500,CW511L,etc |
Working Medium | Water and Non-corrosive liqid | |
Working Pressure | 16 bar | |
Working Temperature | -20℃ to 120℃ | |
Size Range | from 1/2"to 4 | |
Connection type | Thread(BSP.NPT) | |
Production method | Forging +machining | |
Standard Ref | DIN 259/ISO9001 |
1. Premium Material: Made of high-quality brass, the valve offers superior durability and corrosion resistance, ensuring long-lasting performance even in harsh environments.
2. Automatic Flow Control: The spring-loaded mechanism ensures that the valve opens to allow flow when fluid pressure is applied in the forward direction and closes immediately to prevent backflow when pressure reverses. This automatic operation eliminates the need for manual intervention or external power.
3. Reliable Sealing: The valve disc and seat are precision-engineered to provide a tight seal, preventing leakage and
4. Versatile Applications: Suitable for use in a wide range of fluid systems, including hydraulic systems, water supply networks, sewage treatment plants, and petrochemical industries, due to its ability to handle various types of fluids and pressures.
5. Ease of Installation: The valve's straightforward design and standard connections make it easy to install and integrate into new or existing piping systems.
These advantages make the brass spring check valve an ideal choice for controlling fluid flow in a variety of industrial and commercial applications.
